stainless steel security window screen is made from high strength stainless steel wire
through the precision loom weaving. It has the property of resisting of shearing and impact force.
It not only prevent the thefts and bullet but also has elegant appearance. .It is your ideal home decoration product.
material:
stainless steel wire 201,202,304L, 316, 316L
wire diameter:
0.50mm, 0.55mm, 0.60mm , 0.70mm, 0.80mm, 0.90mm, 1.0mm
mesh size: 10*10mesh, 11*11mesh, 12*12mesh, 14*14mesh
surface treatment:
black-matte powder coated, grey, white, brown, yellow, green, various colours as you wish
application:
used in all types of windows and doors
Used in producing security screen that guards your hours anti-theft,anti-mosquito,
anti-pest.It is suitable for advanced door andwindow.This mesh was submitted to
Australian Engineering Laboratories for testing.
advantage:
a ) Prevent from rats, snakes, flies etc.
b ) High strength, can not be kicked in or broken with hammers
c ) Can not be cut with scissors
d ) Fire proof, maximum anti corrosion
e ) Clear from inside,can not be seen thru from outside
f ) Easy to clean
| Security Window Screen Specification Table |
| Material | Mesh | Wire Dia. | Open (mm) | Open Area |
| mm / inch | % |
| SS 316 or 304 | 10 x 10 | 0.9mm /0.035" | 1.64 | 41.7 |
| SS 316 or 304 | 10 x 10 | 1.2mm /0.028" | 1.34 | 27.8 |
| SS 316 or 304 | 10 x 10 | 0.8mm / 0.032" | 1.74 | 46.9 |
| SS 316 or 304 | 10 x 10 | 1.15mm / 0.045" | 1.39 | 29.9 |
| SS 316 or 304 | 11 x 11 | 0.8mm /0.032" | 1.5 | 42.5 |
| SS 316 or 304 | 11 x 11 | 0.7mm / 0.027" | 1.6 | 48.3 |
| SS 316 or 304 | 12 x 12 | 0.7mm / 0.027" | 1.42 | 44.8 |
| SS 316 or 304 | 12 x 12 | 0.58mm / 0.023" | 1.54 | 52.8 |
Special mesh can be made according to customers requirement.
|
